DB-MS01
Size(mm):  28.6×30.1
Power Consumption(Operation mode):0.192W
Active Antenna
Slave control interface: I2C/SPI
Audio output is available via I2S

  • 功能简介
  • 规格参数
1. DAB/DAB+ complies with the DAB spec EN 300 401/TS 102 563
2. Support DAB Band III (174.928 - 239.200 MHz)
3. Dynamic Label Segment (DLS)
4. DAB Slideshow
5. DAB to DAB service following
6. DAB to FM service following
7. Traffic Announcements
8. Soft mute and comfort noise
9. Service list management
10. Support for presets

Parameters Min Typical Max Unit
Tuning range 174.928   239.2 MHz
Sensitivity -95 -100   dBm
Signal to Noise 60 70   dB
Distortion   0.2 0.3 %
Audio output 0.5 0.6   Vpp
Channel Separation RF=1K 0dB 60 70   dB
Channel different RF=1K 0dB ±3 0   dB
RF input impedance   50   Ohm
